Overview

Basic Info.

Model NO.	ZD-FJ
Speed	High
Width	80-540
Size and Shape	12000×3500×2000
Long	190-770
Weight	14000
Material	Paper
Usage	Shopping Bag, Leisure Food Bag, Bread Bags, Fruit Bag, Kfc Bag
Bag Body Width	80-540
Paper Thickness	450-170gms
Max Speed	260bags/Min
Bag Bottom Size	50-254
Paper Roll Width	290-1530
Paper Tube Length	190-770
Model No.	Zd-Fj Series
Transport Package	Vacuum Rustproof Composite Packaging, Wood Pallet
Specification	12000*3500*2000mm
Trademark	Jianshe
Origin	Suzhou, China
HS Code	84412000
Production Capacity	600sets/Year

Product Description

Product Description

This machine is designed to manufacture square bottom paper bags without handles from paper roll, and it is an ideal equipment for producing various sized paper bags fast. By implementing steps including paper feeding, tube forming, tube cutting and bottom forming inline, this machine can effectively save labor costs. The equipped photoelectric detector can correct cutting length, so as to ensure cutting precision. The equipped SIEMENS PLC system ensures that the machine can perform quickly and stably. This machine can process very thin paper, as well as produce paper bags very fast, thus this machine is especially suitable for being applied in food industries.

Detailed Photos

Features
1.This machine can produce paper bags of wide-range sizes. It can produce not only small-size food bags, but also big-size shopping bags.2. This machine can make various kinds of paper bags having different bottom styles.

Product Parameters

Technical Date

	ZD-FJ08	ZD-FJ11E	ZD-FJ13E(S)	ZD-FJ14	ZD-FJ18B(C)	ZD-FJ21(S)
Paper Roll Width	290-630mm	370-890mm	400-990mm (420-1050mm)	590-1150mm	660-1230mm(650-1280mm)	630-1530mm
Max.Paper Roll Diameter	Φ1200mm	Φ1200mm	Φ1200mm	Φ1200mm	Φ1200mm	Φ1200mm
Material Core Diameter	Φ76mm(3")	Φ76mm(3")	Φ76mm(3")	Φ76mm(3")	Φ76mm(3")	Φ76mm(3")
Paper Thickness	45-130g/m²	50-150g/m²	55-160g/m²	80-150g/m²	80-170g/m²	90-170g/m²
Tube Length	190-370mm	270-530mm	270-530mm	340-650mm	270-530mm(380-760mm)	380-770mm
Bag Body Width	80-200mm	110-280mm	125-330mm	200-360mm	260-450mm(220-450mm)	220-540mm
Bag Bottom Size	50-100mm	60-150mm	60-150mm(70-180mm)	80-200mm	60-150mm(90-180mm)	80-210mm(130-254mm)
Max. Speed	260bags/min	240bags/min	220bags/min	150bags/min	130bags/min	120bags/min
Total Power	13.5kw	16kw	16kw	16kw	18.5kw	18.5kw
Total Weight	6000kg	8000kg	8500kg	11000kg	11000kg	14000kg
Overall Dimension	L8500×W3000×H1600mm	L10000×W3300×H2000mm	L10000×W3450×H2000mm	L10500×W3500×H2000mm	L12000×W3500×H2000mm	L11600×W3500×H2000mm

Certifications

Packaging & Shipping

Company Profile

FAQ

Q: Are you manufacturer or trading company?

A: We are the manufacturer and have more than 200 workers
Q: Where is your factory located? May I have a visit?
A: Warmly welcome! Our factories are located in Suzhou and Wenzhou
Q: How is the quality of your machine?
A:History: Our company has nearly 30 years of manufacturing history.Size: Covering an area of 26,600 square meters; more than 100 processing & testing equipments.Products: Paper Bag Machines and Flexographic Printing Machines.Sales: Self-owned import&export rights; Annual output value is more than US$20,000,000
Q: What information should I let you know if I want to get a quotation?
A: First:Paper raw material: Roll-Fed paper or Sheet-Fed Paper.Second:sizes of the paper bag, thickness of paper.Then the most suitable machine will be reccomended to you.
Q: Do you have related machine working video?
A: Yes.
